J1 Wireless Translation Guide System

I. Product Overview

This product is the Timekettle Wireless Translation Guide System, consisting of three components: a Timekettle Fluentalk Translator, a Wireless Bluetooth Transmitter, and Bluetooth Earphones. The three devices are interconnected via Bluetooth to enable real-time translation and wireless guided tour functionality.

The guide speaks into the translator, which performs real-time translation and transmits the audio via Bluetooth to the transmitter. The transmitter then broadcasts the signal wirelessly to all earphones, allowing listeners to receive the translated audio content through their earphones.

This system is suitable for various cross-language communication scenarios including tourism, conferences, training sessions, VIP reception, and museum/exhibition guided tours.

II. Packing List

III. Product Introduction

Device Connection Steps:

For first-time use, the devices come pre-paired. If you need to adjust the device connections, follow these steps:

1. Turn on all three devices (Translator, Transmitter, Earphone)
2. Pair the Translator with the Transmitter via Bluetooth — open the Translator's Bluetooth settings, search for "D313", and connect
3. Pair the Receiver and Earphone channel
4. Begin use

3.1 Timekettle Fluentalk Translator

Translator Packing List

Basic Operations

Power On / Off / Restart

Long press the power button to turn on the translator. Long press again to select Power Off / Restart.

Built-in eSIM Card

Upon first boot, the system will automatically activate the eSIM wireless network. This process takes approximately 2 minutes. Once activated, you can enjoy two years of free data for online translation.

Installing a nano-SIM Card

Insert the SIM eject pin into the small hole on the SIM card tray and push inward to eject the tray. Place the nano-SIM card into the tray frame, then insert the tray back into the translator.

3.2 Wireless Transmitter

3.3 721R Receiver (Bluetooth Earphone)

Parts Diagram

Operating Instructions

1. Power On: Long press the Power Button for 2 seconds. The green indicator light will illuminate, indicating the device is on.
2. Channel Tuning: After powering on, long press Volume -, then press the Power Button 3 times simultaneously. The indicator light will flash, indicating channel searching. When the flashing stops, channel search is successful and the receiver is paired to the current transmitter channel. If the transmitter channel remains unchanged next time, re-pairing is not required.
3. Setup Distance: Must be within 1 meter of the transmitter during channel pairing.
4. Indicator Light Status:
   • Red light — Charging
   • Blue light — Fully charged
   • Alternating red/green — Signal light (connected)
   • Flashing green — Low battery
5. Battery Life: When fully charged, the receiver can operate continuously for 5+ hours.

V. Product Specifications

5.1 Specifications

VI. Frequently Asked Questions

VII. Precautions

• The receiver and transmitter channels must match for proper operation. There is no limit on the number of receivers.
• Do not use more than two transmitters on the same channel at the same time and location.
• Do not use or store the device in dusty, humid, high-temperature, or strong magnetic field environments.
• This device has been calibrated with precision instruments. Do not disassemble it on your own.
• If not used for extended periods, charge the device once every 6 months.
• After the translator's built-in mobile data expires (2 years), you will need to connect to the internet independently (WiFi or SIM mobile data).

Safety Information

Please read the following safety information before using this product:

• Do not charge using non-officially recommended methods to avoid fire, explosion, or other hazards.
• Avoid dropping, burning, crushing, or submerging the product in liquid.
• Do not expose the product to high temperatures or place it near heat-generating devices such as ovens or microwaves.
• Use within 0–35°C; store within -20–45°C.
• We are not responsible for issues caused by the use of non-officially approved accessories.
• Power adapters should be CCC-certified products.
• Improper battery replacement may cause explosion risk. Only replace with the same type of battery.
• Do not expose the battery to sunlight, fire, or overheating environments.

Company Information

Warranty Card

Warranty Terms

• Please retain your proof of purchase and warranty card as warranty credentials.
• From the date of purchase, the product is covered by a 1-year warranty and accessories by a 6-month warranty for quality issues under normal use. Free repair is available with proof of purchase and warranty card. Subject to national Three Guarantees policy.
• Not covered under warranty: Normal wear and tear; damage caused by not following the user manual; damage caused by force majeure.
• For faults caused by human factors, expired warranty, or force majeure, a reasonable repair fee will be charged.
• *The above information is subject to change. Please refer to the official website for the latest updates.
